CORE MASTER TPY0705-101M, INDUCTOR FIXED 100UH 7X7MM SMD

TPY0705-101M
brand logo

HT Part No. HT194791

Mfr. Part No. TPY0705-101M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.26
Units Per Unit Price
1 - 999 £ 0.26
1000 + £ 0.22
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Width 7.00mm
Manufacturer CORE MASTER
Pitch None
Current - Saturation (Isat) N/A
Tolerance ±20%
Technology Wire Wound
Inductance 100uH
Current Rating 1A
DC Resistance (DCR) 1 Ohms
Length 7.00mm
Package / Case Non Standard
Applications General Purpose
Diameter N/A
Height 4.60mm
Operation Temperature N/A
Packaging TAPE&REEL
Series TPY
Mounting Type SMT
Shielding Unshielded
Rohs ROHS

More Information

The CORE MASTER TPY0705-101M is a fixed inductor with a 100µH inductance, designed to provide superior performance in various electronic applications. Encased in a 7x7mm surface-mount device (SMD) package, this inductor is tailored for compact, high-density designs. Featuring low resistance and high current handling capability, the TPY0705-101M ensures minimal energy loss and efficient power delivery. Its robust construction offers excellent reliability and stability under diverse operating conditions, making it ideal for demanding environments. This inductor is perfect for applications requiring consistent performance and space efficiency.

Potential Benefits of Using the CORE MASTER TPY0705-101M, Power Inductor Fixed

  • High current handling capability
  • Excellent reliability and stability
  • Reduces energy loss
  • Enhances power efficiency
  • Suitable for high-density designs
  • Reliable performance in various conditions

Versatility in Applications

The CORE MASTER TPY0705-101M is an optimal choice for engineers seeking high-quality inductors for their electronic designs, such as:

  • Power Supply Modules
  • DC-DC Converters
  • Filtering Applications
  • Consumer Electronics
  • Industrial Equipment
