CORE MASTER WHI0603-39NJ-N, INDUCTOR FIXED 0603 39NH SMD

WHI0603-39NJ-N
brand logo

HT Part No. HT194780

Mfr. Part No. WHI0603-39NJ-N

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

620 - In Stock pcs
Price:
£ 0.097
Units Per Unit Price
2 - 3999 £ 0.097
4000 + £ 0.081
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
DC Resistance (DCR) 250m Ohms
Height 1.02mm
Manufacturer CORE MASTER
Rohs ROHS
Packaging TAPE&REEL
Mounting Type SMT
Technology Wire Wound
Tolerance ±5%
Series WHI
Shielding Unshielded
Current Rating 600mA
Current - Saturation (Isat) N/A
Pitch None
Inductance 39nH
Applications General Purpose
Diameter N/A
Length 1.80mm
Width 1.12mm
Operation Temperature N/A
Package / Case 0603 (1608 Metric)

More Information

The CORE MASTER WHI0603-39NJ-N is a high-performance fixed inductor designed for SMD (Surface-Mount Device) applications. With its compact 0603 footprint and 39nH inductance value, this inductor provides efficient power management in space-constrained electronic circuits. It features a low DC resistance, which minimises power loss and enhances overall circuit efficiency. The WHI0603-39NJ-N is engineered for high-frequency applications, ensuring stable performance and reliable signal integrity.

Salient Features and Benefits of the CORE MASTER WHI0603-39NJ-N, Fixed Inductor SMD

  • Low DC resistance for reduced power loss
  • High-frequency stability for reliable performance
  • Ideal for compact, high-density electronic circuits
  • Improves circuit efficiency and performance
  • Ensures stable operation in high-frequency applications

Application Information of the Fixed Inductor SMD

  • RF and Microwave Circuits
  • Communication Devices
  • Power Management Systems
