CORE MASTER NR3015-220M, INDUCTOR FIXED 10UH 3X3X1.5MM SMD

NR3015-220M
brand logo

HT Part No. HT194753

Mfr. Part No. NR3015-220M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

40 - In Stock pcs
Price:
£ 0.089
Units Per Unit Price
2 - 1999 £ 0.089
2000 + £ 0.073
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case Non Standard
Applications General Purpose
Length 3.00mm
Pitch None
Inductance 22uH
Operation Temperature N/A
Series NR
Technology Wire Wound
Height 1.50mm
Mounting Type SMT
Current - Saturation (Isat) N/A
Diameter N/A
Width 3.00mm
Packaging TAPE&REEL
Manufacturer CORE MASTER
Shielding Shielded
Current Rating 470mA
Tolerance ±20%
DC Resistance (DCR) 622m Ohms
Rohs ROHS

More Information

The CORE MASTER NR3015-220M is a high-performance fixed inductor offering 10µH inductance with a compact 3x3x1.5mm SMD package. This inductor is designed to provide exceptional efficiency and reliability in various electronic applications. Its robust construction ensures high current handling capabilities, making it ideal for power management in compact devices.

Unique Advantages of the CORE MASTER NR3015-220M, Power Inductor Fixed

  • Space-saving design suitable for compact electronic devices
  • Reliable performance in high-current applications
  • Enhanced efficiency and longevity of electronic devices
  • High current handling capabilities
  • Excellent heat dissipation

Versatility in Applications

  • Power Management in Portable Devices
  • DC-DC Converters
  • LED Drivers
  • Consumer Electronics
  • Telecommunications Equipment
