FPI0502F-220M - INDUCTOR POWER 22UH 5.8X5.2mm SMD

FPI0502F-220M
brand logo

HT Part No. HT194730

Mfr. Part No. FPI0502F-220M

Manufacturer: TAI-TECH

Technical Documents: Datasheet(datasheets)

47680 - In Stock pcs
Price:
£ 0.13
Units Per Unit Price
1 - 2999 £ 0.13
3000 + £ 0.11
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current - Saturation (Isat) N/A
DC Resistance (DCR) 500m Ohms
Operation Temperature N/A
Package / Case Non Standard
Inductance 22uH
Current Rating 500mA
Applications General Purpose
Technology Power
Shielding Unshielded
Diameter N/A
Height 2.00mm
Packaging TAPE&REEL
Manufacturer TAI-TECH
Series FPI
Mounting Type SMT
Length 5.80mm
Width 5.20mm
Pitch None
Tolerance ±20%
Rohs ROHS

More Information

The TAI-TECH 531146 is a surface mount inductor, also known as a Film Power indicator (FPI),  designed to regulate and store electrical current within electronic circuits.  This specific model boasts an inductance of 500 microhenrys (uH).

Unique Advantages

  • Induces a voltage that opposes changes in current flow, helping to maintain stable current levels within a circuit.
  • It can store and release small amounts of electrical energy, which is helpful in filtering noise or creating voltage spikes in circuits.
  • The surface mount design allows for space-saving integration into various electronic devices.

Usage Information

The TAI-TECH 531146 finds use in a wide range of electronic applications due to its ability to control and manage current flow:

  • Power Supplies: Improves stability and efficiency within power supply circuits.
  • Noise Filtering: Filters out unwanted high-frequency noise in electronic signals.
  • DC-DC Converters: Plays a crucial role in regulating voltage levels within DC-DC converter circuits.
  • RF (Radio Frequency) Applications: Can be utilised in circuits for radio frequency devices like antennas or filters.
