VIKING NL12KTC100-M, INDUCTOR WIREWOUND 1812 10uH 550mA SMD

NL12KTC100-M
brand logo

HT Part No. HT194719

Mfr. Part No. NL12KTC100-M

Manufacturer: VIKING

Technical Documents: Datasheet(datasheets)

26841 - In Stock pcs
Price:
£ 0.10
Units Per Unit Price
1 - 499 £ 0.10
500 + £ 0.089
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Manufacturer VIKING
Tolerance ±10%
Length 4.50mm
Width 3.20mm
Height 3.20mm
Technology Wire Wound
Rohs ROHS
Packaging TAPE&REEL
Series NL-C
Mounting Type SMT
Inductance 10uH
Current - Saturation (Isat) N/A
DC Resistance (DCR) 500m Ohms
Diameter N/A
Package / Case 1812 (4532 Metric)
Pitch None
Shielding Unshielded
Current Rating 550mA
Applications General Purpose
Operation Temperature -40°C ~ +85°C

More Information

The VIKING NL12KTC100-M is a robust wire-wound inductor designed for surface-mount applications. It features a compact 1812 size and offers a 10µH inductance with a 550mA current rating, making it ideal for use in various electronic circuits. This inductor boasts high efficiency, low DC resistance, and excellent heat dissipation, ensuring reliable performance in demanding conditions. Its SMD design allows for easy integration into automated assembly processes, providing cost-effective solutions for high-volume production.

Possible Advantages of Using the VIKING NL12KTC100-M, Wire Wound Inductor

  • Surface Mount Design
  • Reliable performance under demanding conditions
  • Efficient heat dissipation
  • Easy integration into automated assembly processes

The VIKING NL12KTC100-M, Wire Wound Inductor: Use Cases

The VIKING NL12KTC100-M is an excellent choice for engineers seeking a dependable inductor for various electronic projects, such as:

  • Power Supply Circuits
  • Filtering Applications
  • Signal Processing
  • DC-DC Converters
  • RF Circuits
