MURATA LQM18FN100M00D, INDUCTOR FIXED 0603 10UH 50mA SMD

LQM18FN100M00D
brand logo

HT Part No. HT194715

Mfr. Part No. LQM18FN100M00D

Manufacturer: MURATA

Technical Documents: Datasheet(datasheets)

24242 - In Stock pcs
Price:
£ 0.097
Units Per Unit Price
5 - 3999 £ 0.097
4000 + £ 0.081
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Manufacturer MURATA
Length 1.60mm
Series LQM18
Tolerance ±20%
Applications General Purpose
Diameter N/A
Mounting Type SMT
Shielding Shielded
DC Resistance (DCR) 1.17 Ohms
Width 0.80mm
Height 0.80mm
Package / Case 0603 (1608 Metric)
Pitch None
Technology Multilayer
Current Rating 50mA
Current - Saturation (Isat) N/A
Inductance 10uH
Operation Temperature -55°C ~ +125°C
Rohs ROHS
Packaging TAPE&REEL

More Information

The MURATA LQM18FN100M00D is a compact, high-performance fixed inductor designed in an 0603 surface-mount package. With an inductance of 10µH and a current rating of 50mA, this inductor is ideal for a variety of electronic applications. Its small size and low profile make it perfect for space-constrained designs, while its high Q value ensures efficient energy storage and low signal loss. The LQM18FN100M00D also features excellent DC bias characteristics, providing stable inductance over a wide range of currents.

Potential Advantages of Using the MURATA LQM18FN100M00D, Power Inductor Fixed

  • Excellent DC bias characteristics
  • Compact size for space-saving designs
  • Low signal loss
  • Stable performance under varying currents

Application Areas of the Power Inductor Fixed

  • Power Supply Circuits
  • Signal Filtering
  • Noise Suppression
  • Portable Devices
  • Communication Equipment
