WURTH 7447714560, FIXED IND 56UH 2A 121 MOHM SMD

WURTH 7447714560, FIXED IND 56UH 2A 121 MOHM SMD
7447714560
brand logo

HT Part No. HT194692

Mfr. Part No. 7447714560

Manufacturer: WURTH

Technical Documents:

14 - In Stock pcs
Price:
£ 1.34
Units Per Unit Prices
1 - 499 £ 1.34
500 + £ 1.22
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type SMT
Operation Temperature -40°C ~ +150°C
Rohs ROHS
Pitch None
Technology Power
Current Rating 2A
Length 10.00mm
Package / Case Non Standard
Applications Automotive(AEC-Q200)
Diameter N/A
Packaging TAPE&REEL
Shielding Shielded
Tolerance ±20%
Width 10.00mm
Height 5.00mm
Manufacturer WURTH
Series WE-PD
Inductance 56uH
Current - Saturation (Isat) N/A
DC Resistance (DCR) 101m Ohms

More Information

The Würth Elektronik 7447714560 is a 56µH fixed inductor designed for surface mount (SMD) applications. This component boasts a robust construction and high current handling capacity of 2A, making it suitable for demanding power electronics circuits. The inductor's low DC resistance (121 mOhm) minimises power loss, enhancing overall system efficiency. Its compact size and shielded design contribute to improved electromagnetic compatibility (EMC) performance.

What Are the Unique Benefits of the Würth Elektronik 7447714560, Fixed Power Inductor?

  • Shielded Design
  • High efficiency
  • Low power loss
  • Compact size
  • Improved EMC performance
  • Reliable performance

Versatile Uses of the Würth Elektronik 7447714560, Fixed Power Inductor

  • DC-DC Converters
  • Power Supplies
  • Filters
  • Automotive Electronics
  • Industrial Control Systems
