MURATA LQW15ANR10J00D, INDUCTOR FIXED 0402 100 nH 120MA 2.52 OHM

LQW15ANR10J00D
brand logo

HT Part No. HT194663

Mfr. Part No. LQW15ANR10J00D

Manufacturer: MURATA

Technical Documents: Datasheet(datasheets)

7890 - In Stock pcs
Price:
£ 0.11
Units Per Unit Price
2 - 9999 £ 0.11
10000 + £ 0.097
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Applications General Purpose
Rohs ROHS
Mounting Type SMT
Current - Saturation (Isat) N/A
Width 0.50mm
Series LQW15
Package / Case 0402 (1005 Metric)
Length 1.00mm
Height 0.50mm
Technology Wire Wound
Shielding Unshielded
Inductance 100nH
Current Rating 120mA
Tolerance ±5%
Manufacturer MURATA
Pitch None
DC Resistance (DCR) 2.52 Ohms
Diameter N/A
Operation Temperature -55°C ~ +125°C
Packaging TAPE&REEL

More Information

The MURATA LQW15ANR10J00D is a high-quality fixed inductor designed for a range of electronic applications. This inductor offers a compact 0402 package, making it ideal for space-constrained designs. With an inductance of 100 nH and a current rating of 120mA, it provides stable performance for various high-frequency circuits. The inductor's low DC resistance of 2.52 ohms ensures minimal power loss, enhancing energy efficiency in your applications. The LQW15ANR10J00D is a reliable choice for engineers seeking to optimise their designs with compact and efficient components.

Significant Benefits Offered By the MURATA LQW15ANR10J00D, Fixed Power Inductor

  • Compact 0402 package size
  • Space-saving design
  • Enhanced energy efficiency
  • Stable performance in high-frequency circuits

Where to Use the MURATA LQW15ANR10J00D, Fixed Power Inductor?

  • RF Circuits
  • Mobile Devices
  • Telecommunications
  • Power Management Systems
