CORE MASTER TPY0705-221M, INDUCTOR FIXED 220UH 7X7MM SMD

TPY0705-221M
brand logo

HT Part No. HT194648

Mfr. Part No. TPY0705-221M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

2851 - In Stock pcs
Price:
£ 0.26
Units Per Unit Price
1 - 999 £ 0.26
1000 + £ 0.22
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Technology Wire Wound
Inductance 220uH
Operation Temperature N/A
Tolerance ±20%
Diameter N/A
Length 7.00mm
Rohs ROHS
Pitch None
Current Rating 550mA
Current - Saturation (Isat) N/A
DC Resistance (DCR) 2 Ohms
Applications General Purpose
Manufacturer CORE MASTER
Series TPY
Shielding Unshielded
Width 7.00mm
Height 4.60mm
Mounting Type SMT
Package / Case Non Standard
Packaging TAPE&REEL

More Information

The CORE MASTER TPY0705-221M is a fixed inductor with a 220μH inductance value designed in a 7x7mm Surface-Mount Device (SMD) package. When electrical current passes through it, this inductor stores energy in a magnetic field.

Possible Advantages of Using the CORE MASTER TPY0705-221M, Fixed Inductor

  • Compact Size: Saves space on PCB boards, ideal for modern, compact electronic designs.
  • High Efficiency: Minimises energy losses due to low DC resistance.
  • Reliability: Durable construction suitable for high-reliability applications.
  • Performance: High Q factor ensures stable performance over a range of frequencies.

Versatile Uses of the CORE MASTER TPY0705-221M, Fixed Inductor

  • Power Supplies: Used in DC-DC converters and power management systems.
  • RF Circuits: Employed in radio frequency circuits for filtering and tuning.
  • Signal Processing: Utilised in signal filtering and noise suppression.
  • Automotive Electronics: Suitable for automotive electronic systems requiring compact and reliable components.
