HCL1005-2N7S-N - INDUCTOR FIXED 0402 2.7nH SMD

HCL1005-2N7S-N
brand logo

HT Part No. HT194647

Mfr. Part No. HCL1005-2N7S-N

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

4700 - In Stock pcs
Price:
£ 0.0081
Units Per Unit Price
50 - 9999 £ 0.0081
10000 + £ 0.0081
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Rohs ROHS
Manufacturer CORE MASTER
Shielding Unshielded
Package / Case 0402 (1005 Metric)
Pitch None
Tolerance ±0.3nH
Applications General Purpose
Packaging TAPE&REEL
Mounting Type SMT
Inductance 2.7nH
Length 1.00mm
Height 0.50mm
Operation Temperature N/A
Series HCL
Technology Multilayer
Current Rating 400mA
Current - Saturation (Isat) N/A
DC Resistance (DCR) 150m Ohms
Diameter N/A
Width 0.50mm

More Information

The CORE MASTER 526035 is a fixed inductor specifically designed for surface mount applications on electronic devices.  It offers a compact solution measuring just 1.00mm x 0.60mm and provides a consistent inductance of 1.00 microhenries.

Possible Advantages

  • Small size: Enables space-saving integration into compact electronic devices.
  • High performance: Consistent inductance ensures reliable circuit operation.

Application Areas

These features make the CORE MASTER 526035 suitable for various applications, including:

  • RF circuits: Used for filtering, impedance matching, and signal conditioning in radio frequency circuits.
  • Power electronics: Can be found in DC-DC converters and other power supply circuits.
