MURATA LQW15AN2N7C00D, INDUCTOR FIXED 0402 2.7nH SMD

LQW15AN2N7C00D
brand logo

HT Part No. HT194639

Mfr. Part No. LQW15AN2N7C00D

Manufacturer: MURATA

Technical Documents: Datasheet(datasheets)

4391 - In Stock pcs
Price:
£ 0.040
Units Per Unit Price
10 - 9999 £ 0.040
10000 + £ 0.032
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series LQW15
Package / Case 0402 (1005 Metric)
Shielding Unshielded
DC Resistance (DCR) 50m Ohms
Diameter N/A
Length 1.00mm
Mounting Type SMT
Technology Wire Wound
Operation Temperature -55°C ~ +125°C
Rohs ROHS
Inductance 2.7nH
Current Rating 850mA
Tolerance ±0.2nH
Applications General Purpose
Packaging TAPE&REEL
Manufacturer MURATA
Pitch None
Current - Saturation (Isat) N/A
Width 0.50mm
Height 0.50mm

More Information

The Murata LQW15AN2N7C00D is a compact 0402 SMD inductor with a fixed inductance of 2.7nH. This tiny component, uniquely designed for high-frequency applications, stands out with its small size and low parasitic elements, crucial for such applications. Constructed with a drum core and wire wound technology, it offers excellent performance characteristics.

Potential Benefits of Using the Murata LQW15AN2N7C00D, SMD Power Inductor

  • Improves circuit stability and performance
  • Reduces electromagnetic interference (EMI)
  • Enhances power supply efficiency
  • Suitable for various high-frequency applications

The Murata LQW15AN2N7C00D, SMD Power Inductor: Versatility in Applications

  • RF and Microwave Circuits
  • Power Supply Filters
  • Signal Integrity Applications
  • High-Speed Data Communication

Key Features of the Power Inductor Include

  • Small 0402 package for space-saving designs
  • High current handling capacity of 850mA
  • Low DC resistance (50mOhm) for efficient power delivery
  • Wide operating temperature range (-55°C to +125°C)
