CORE MASTER WCI3225C-220K-N, INDUCTOR FIXED 1210 22UH SMD

WCI3225C-220K-N
brand logo

HT Part No. HT194631

Mfr. Part No. WCI3225C-220K-N

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

901 - In Stock pcs
Price:
£ 0.14
Units Per Unit Price
1 - 1999 £ 0.14
2000 + £ 0.12
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Inductance 22uH
Current Rating 210mA
Width 2.50mm
Series WCIC
Mounting Type SMT
Current - Saturation (Isat) N/A
Diameter N/A
Manufacturer CORE MASTER
Technology Wire Wound
Tolerance ±10%
DC Resistance (DCR) 2.2 Ohms
Packaging TAPE&REEL
Package / Case 1210 (3225 Metric)
Pitch None
Shielding Shielded
Applications General Purpose
Length 3.20mm
Height 2.20mm
Operation Temperature N/A
Rohs ROHS

More Information

The CORE MASTER WCI3225C-220K-N is a high-performance, fixed inductor designed in a compact 1210 SMD package. With an inductance of 22µH, this component is ideal for numerous electronic applications. It features a low DC resistance, ensuring minimal power loss, and high current handling capability, making it suitable for power supply circuits and DC-DC converters. The WCI3225C-220K-N's small size and surface-mount design allow for easy integration into modern electronic devices, saving space and improving overall efficiency.

Unique Advantages of the CORE MASTER WCI3225C-220K-N, Fixed Power Inductor

  • Low DC resistance
  • High current handling capability
  • Efficient power management
  • Space-saving design
  • Reliable performance

Where to Use the CORE MASTER WCI3225C-220K-N, Fixed Power Inductor?

The CORE MASTER WCI3225C-220K-N is a versatile choice for engineers seeking reliable inductors for their electronic designs, including:

  • Power Supply Circuits
  • DC-DC Converters
  • Signal Filtering
  • Energy Storage Systems
