CORE MASTER SPI1005-220M, INDUCTOR POWER 22UH 10.5X10.5 CLOSE TYPE

SPI1005-220M
brand logo

HT Part No. HT194617

Mfr. Part No. SPI1005-220M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

2937 - In Stock pcs
Price:
£ 0.36
Units Per Unit Price
1 - 499 £ 0.36
500 + £ 0.31
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series SPI
Length 10.50mm
Manufacturer CORE MASTER
Rohs ROHS
Mounting Type SMT
DC Resistance (DCR) 59m Ohms
Applications General Purpose
Technology Wire Wound
Shielding Shielded
Current Rating 2.5A
Tolerance ±20%
Diameter N/A
Width 10.50mm
Package / Case Non Standard
Pitch None
Inductance 22uH
Current - Saturation (Isat) N/A
Height 5.00mm
Operation Temperature N/A
Packaging TAPE&REEL

More Information

The CORE MASTER SPI1005-220M is a high-performance power inductor designed for efficient energy storage and filtering in compact electronic devices. With its 22µH inductance and close-type construction, this inductor ensures reliable performance in space-constrained applications. Its dimensions of 10.5x10.5mm make it a perfect fit for small electronic circuits, providing exceptional stability and minimal core losses. The SPI1005-220M is engineered to handle high currents while maintaining low resistance, reducing heat generation and enhancing overall circuit efficiency.

Special Features and Benefits of Using the CORE MASTER SPI1005-220M, Power Inductor SMD

  • 22µH inductance for reliable energy storage
  • Close-type construction for reduced electromagnetic interference
  • High current handling capability
  • Enhanced circuit efficiency and stability
  • Minimal core losses and heat generation
  • Ideal for space-constrained designs

Application Versatility of the CORE MASTER SPI1005-220M, Power Inductor SMD

  • Power Supplies
  • DC-DC Converters
  • Consumer Electronics
  • Automotive Electronics
