SMPI06050-220M - INDUCTOR POWER 22UH 7.7X6.6MM SMD

SMPI06050-220M
brand logo

HT Part No. HT194551

Mfr. Part No. SMPI06050-220M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

1059 - In Stock pcs
Price:
£ 0.28
Units Per Unit Price
1 - 999 £ 0.28
1000 + £ 0.25
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type SMT
DC Resistance (DCR) 115m Ohms
Diameter N/A
Height 5.00mm
Shielding Shielded
Current Rating 5A
Applications General Purpose
Inductance 22uH
Current - Saturation (Isat) N/A
Tolerance ±20%
Manufacturer CORE MASTER
Package / Case Non Standard
Operation Temperature N/A
Series SMPI
Pitch None
Technology Power
Length 7.70mm
Width 6.00mm
Rohs ROHS
Packaging TAPE&REEL

More Information

The CORE MASTER SMPI06050-220M, a power inductor with a 22µH inductance value and a compact 7.7x6.6mm SMD package, is a versatile solution that adapts seamlessly to a wide range of high-frequency applications.

Primary Functions of the CORE MASTER SMPI06050-220M, Power Inductor

  • Store power in a magnetic field when electrical current flows through it.
  • Filter and smooth out voltage fluctuations in power supplies.
  • Reduce electromagnetic interference (EMI).

What Are the Benefits of the CORE MASTER SMPI06050-220M, Inductor Power 22uH 7.7x6.6mm SMD?

  • Enhances efficiency and performance of power supply circuits
  • Ensures stable current flow and voltage regulation
  • Minimises power losses and heat generation
  • Supports high-frequency operations with minimal signal loss

Application Areas of the CORE MASTER SMPI06050-220M, Inductor Power 22uH 7.7x6.6mm SMD

  • DC-DC Converters
  • Power Supply Modules
  • Telecommunications Equipment
  • Consumer Electronics
  • Automotive Electronics

Technical Insights Include

  • High energy storage capacity
  • Compact and space-saving design
  • Excellent DC bias characteristics
  • Low core loss
