CORE MASTER SDI105R-101M, INDUCTOR POWER 100UH 10.3X10.5MM SMD

SDI105R-101M
brand logo

HT Part No. HT194547

Mfr. Part No. SDI105R-101M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

79 - In Stock pcs
Price:
£ 0.26
Units Per Unit Price
1 - 499 £ 0.26
500 + £ 0.23
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Shielding Shielded
Height 5.00mm
Operation Temperature N/A
Rohs ROHS
Series SDI
Pitch None
Current Rating 1A
Diameter N/A
Packaging TAPE&REEL
Mounting Type SMT
Current - Saturation (Isat) N/A
Applications General Purpose
Manufacturer CORE MASTER
Package / Case Non Standard
Technology Power
Inductance 100uH
Tolerance ±20%
DC Resistance (DCR) 210m Ohms
Length 10.50mm
Width 10.30mm

More Information

The CORE MASTER SDI105R-101M is a high-quality power inductor with a 100µH inductance value, specifically designed for surface-mount applications. It features a compact size of 10.3x10.5mm, making it ideal for space-constrained designs. This inductor is crafted with superior materials to ensure low core loss and high efficiency, which is crucial for power-sensitive applications. The SDI105R-101M is perfect for use in power supply circuits, DC-DC converters, and filtering applications, where stable inductance and minimal signal distortion are critical.

Standout Features and Benefits of Using the CORE MASTER SDI105R-101M, Power Inductor

  • High efficiency and low core loss
  • Surface-mount design
  • Saves space in compact designs
  • Enhances power supply efficiency
  • Reduces electromagnetic interference (EMI)
  • Reliable performance in high-frequency applications

Application Versatility of the CORE MASTER SDI105R-101M, Power Inductor

  • Power Supply Circuits
  • DC-DC Converters
  • Signal Filtering
  • Telecommunications Equipment
  • Consumer Electronics
