COILMASTER SDO3316-101M-LF, INDUCTOR POWER 100uH 12.95x9.40x5.20mm SMD

SDO3316-101M-LF
brand logo

HT Part No. HT194539

Mfr. Part No. SDO3316-101M-LF

Manufacturer: COILMASTER

Technical Documents: Datasheet(datasheets)

939 - In Stock pcs
Price:
£ 0.50
Units Per Unit Price
1 - 999 £ 0.50
1000 + £ 0.44
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Technology Wire Wound
Inductance 100uH
Manufacturer COILMASTER
Diameter N/A
Height 5.20mm
Packaging TAPE&REEL
Mounting Type SMT
Pitch None
Current Rating 1.3A
Current - Saturation (Isat) N/A
DC Resistance (DCR) 280m Ohms
Tolerance ±20%
Applications General Purpose
Rohs ROHS
Series SDO
Package / Case Non Standard
Shielding Unshielded
Length 12.95mm
Width 9.40mm
Operation Temperature -40°C ~ +125°C

More Information

The COILMASTER SDO3316-101M-LF is a high-performance power inductor designed for compact and efficient electronic applications. Measuring just 12.95x9.40x5.20mm, this surface-mount device offers a 100µH inductance value, ideal for handling high-current operations in space-constrained environments. Its low-profile design and high saturation current capability make it suitable for use in demanding conditions where reliability and performance are critical. The SDO3316-101M-LF features a ferrite core that enhances its efficiency and reduces energy loss, while its low DC resistance ensures minimal heat generation and improved power handling.

Benefits You Get

  • Compact Size: Ideal for space-limited applications
  • High Saturation Current Capability: Reliable performance under heavy loads
  • Efficient Power Handling: Reduces energy loss and heat generation

Usage Information of the COILMASTER SDO3316-101M-LF, Power Inductor SMD

  • Power Supplies: Ensures stable operation in voltage regulators and converters
  • Automotive Electronics: Reliable performance in demanding environments
  • Consumer Electronics: Suitable for use in portable devices and compact gadgets
