IHLP4040DZER220M11 - INDUCTOR FIXED 22UH SMD

IHLP4040DZER220M11
brand logo

HT Part No. HT194523

Mfr. Part No. IHLP4040DZER220M11

Manufacturer: VISHAY DALE

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.62
Units Per Unit Price
1 - 499 £ 0.62
500 + £ 0.54
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type SMT
Inductance 22uH
Applications General Purpose
Package / Case Non Standard
Pitch None
Operation Temperature -55°C ~ +125°C
Shielding Shielded
DC Resistance (DCR) 60.4m Ohms
Diameter N/A
Length 10.79mm
Manufacturer VISHAY DALE
Series IHLP
Current Rating 5A
Current - Saturation (Isat) N/A
Technology Molded
Tolerance ±20%
Width 10.16mm
Height 4.00mm
Rohs ROHS
Packaging TAPE&REEL

More Information

The VISHAY DALE IHLP4040DZER220M11 is a high-performance fixed power inductor known for its efficiency and reliability in various electronic applications. This surface-mount device (SMD) features a fixed inductance value of 22µH, making it ideal for use in power management systems. It is an electrical device that stores power in a magnetic field when electric power flows through the component.

Possible Advantages of Using the VISHAY DALE IHLP4040DZER220M11, Fixed Power Inductor

  • Provides low DC resistance and high current handling capabilities.
  • Ideal for space-constrained applications due to its small footprint.
  • Stable performance under varying temperatures and current conditions.
  • Compatible with automated pick-and-place assembly processes.

Where Can I Use the VISHAY DALE IHLP4040DZER220M11, Fixed Power Inductor?

This component's robust design and versatile applications make it valuable for engineers and designers seeking reliable performance in demanding environments such as:

  • Power Management: Used in voltage regulators, DC-DC converters, and power supplies.
  • Telecommunications: Integral in RF applications and signal filtering.
  • Automotive Electronics: Supports engine control units, infotainment systems, and battery management.
  • Consumer Electronics: Employed in smartphones, tablets, and other portable devices for power regulation.
