BOURNS SDR0805-680KL, INDUCTOR POWER 68uH 7.80x5.30mm SMD

SDR0805-680KL
brand logo

HT Part No. HT194499

Mfr. Part No. SDR0805-680KL

Manufacturer: BOURNS

Technical Documents: Datasheet(datasheets)

2 - In Stock pcs
Price:
£ 0.45
Units Per Unit Price
1 - 999 £ 0.45
1000 + £ 0.39
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Width 7.80mm
Rohs ROHS
Length 7.80mm
Operation Temperature -40°C ~ +125°C
Package / Case Non Standard
Applications General Purpose
Manufacturer BOURNS
Technology Wire Wound
Current - Saturation (Isat) N/A
Tolerance ±20%
Diameter N/A
Series SDR
Mounting Type SMT
Pitch None
Shielding Unshielded
Inductance 68uH
Current Rating 3.7A
DC Resistance (DCR) 30m Ohms
Height 5.30mm
Packaging TAPE&REEL

More Information

The BOURNS SDR0805-680KL is a compact and efficient power inductor designed for high-frequency applications. This surface-mount device (SMD) features a 68 µH inductance value and measures 7.80 x 5.30 mm, making it suitable for tight spaces and high-density circuit designs. Due to its low DC resistance and high saturation current capability, it is ideal for use in power supply circuits, DC-DC converters, and EMI filtering applications. The BOURNS SDR0805-680KL offers enhanced performance with minimal interference, contributing to stable and reliable circuit operation.

Standout Features and Benefits of Using the BOURNS SDR0805-680KL, Power Inductor

  • Surface-mount design
  • Low DC resistance
  • High saturation current
  • Compact size for space-constrained designs
  • Reliable performance with minimal interference
  • Efficient power handling and low energy loss

Where Can I Use the BOURNS SDR0805-680KL, Power Inductor?

  • Power Supply Circuits
  • Dc-Dc Converters
  • EMI Filters
