FH VHF100505HQ15NJT, INDUCTOR FIXED 0402 15NH SMD

VHF100505HQ15NJT
brand logo

HT Part No. HT194489

Mfr. Part No. VHF100505HQ15NJT

Manufacturer: FH

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0
Units Per Unit Price
100 - 9999 £ 0
10000 + £ 0
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Length 1.00mm
Series VHF
Package / Case 0402 (1005 Metric)
Manufacturer FH
Tolerance ±5%
Operation Temperature -55°C ~ +125°C
Rohs ROHS
Mounting Type SMT
Pitch None
Shielding Shielded
Diameter N/A
Packaging TAPE&REEL
Technology Wire Wound
Inductance 15nH
Current Rating 300mA
Current - Saturation (Isat) N/A
DC Resistance (DCR) 500m Ohms
Applications General Purpose
Width 0.50mm
Height 0.50mm

More Information

The FH VHF100505HQ15NJT is a high-quality fixed inductor designed for surface-mount applications, specifically in a 0402-package size. This inductor, with a nominal inductance of 15 nH, is a crucial component in various electronic circuits, particularly for RF and high-frequency applications. Its compact size and SMD (Surface Mount Device) design make it ideal for modern electronics where space and weight are critical factors. The inductor offers stable inductance over a wide frequency range, low DC resistance, and excellent current handling capability.

Special Features and Benefits of Using the FH VHF100505HQ15NJT, Fixed Inductor

  • Low DC Resistance: Enhances efficiency
  • High-frequency stability: Suitable for RF applications
  • Compact Design: Saves space on PCB
  • High Performance: Reliable operation in high-frequency circuits
  • Energy Efficiency: Low power loss

Versatile Uses of the FH VHF100505HQ15NJT, Fixed Inductor

This component is essential in modern electronic devices, ensuring efficient operation and high-performance standards, such as:

  • RF Circuits: Improves signal integrity
  • Filters: Used in high-frequency filtering applications
  • Impedance Matching: Essential in tuning circuits for optimal performance
