VISHAY DALE IMC1812ES821K, INDUCTOR FIXED 1812 820uH 30mA SMD

IMC1812ES821K
brand logo

HT Part No. HT194473

Mfr. Part No. IMC1812ES821K

Manufacturer: VISHAY DALE

Technical Documents: Datasheet(datasheets)

23850 - In Stock pcs
Price:
£ 0.19
Units Per Unit Price
1 - 1999 £ 0.19
2000 + £ 0.16
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Technology Wire Wound
Height 3.40mm
Rohs ROHS
Current - Saturation (Isat) N/A
Tolerance ±10%
Diameter N/A
Manufacturer VISHAY DALE
Pitch None
Operation Temperature -55°C ~ +125°C
Package / Case 1812 (4532 Metric)
DC Resistance (DCR) 35 Ohms
Applications General Purpose
Width 3.20mm
Packaging TAPE&REEL
Series ICM
Mounting Type SMT
Shielding Unshielded
Inductance 820uH
Current Rating 30mA
Length 4.50mm

More Information

The VISHAY DALE IMC1812ES821K is a high-performance fixed inductor designed for surface-mount applications. With an inductance of 820µH and a current rating of 30mA, this component is ideal for compact electronic designs requiring stable inductance values and efficient energy storage. Its 1812 package ensures it fits seamlessly onto standard printed circuit boards, making it suitable for a wide range of electronic devices. It offers exceptional reliability and efficiency, making it a preferred choice for engineers looking to optimise their electronic designs for performance and durability.

Unique Advantages of Using the VISHAY DALE IMC1812ES821K, Power Inductor SMD

  • Compact design for space-saving in PCB layouts
  • Reliable performance in energy storage and filtering
  • Enhanced durability with a robust construction

Use Cases of the VISHAY DALE IMC1812ES821K, Power Inductor SMD

  • Power Supply Circuits
  • RF Signal Processing
  • Filter Circuits
  • Communication Devices
