CORE MASTER SDI105R-680M, INDUCTOR POWER 68UH 10.3X10.5MM SMD

SDI105R-680M
brand logo

HT Part No. HT194461

Mfr. Part No. SDI105R-680M

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

504 - In Stock pcs
Price:
£ 0.27
Units Per Unit Price
1 - 499 £ 0.27
500 + £ 0.23
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Technology Power
DC Resistance (DCR) 201m Ohms
Packaging TAPE&REEL
Mounting Type SMT
Diameter N/A
Height 5.00mm
Series SDI
Shielding Shielded
Inductance 68uH
Width 10.30mm
Manufacturer CORE MASTER
Current Rating 1.5A
Tolerance ±20%
Length 10.50mm
Package / Case Non Standard
Pitch None
Current - Saturation (Isat) N/A
Applications General Purpose
Operation Temperature N/A
Rohs ROHS

More Information

The CORE MASTER SDI105R-680M is a high-performance power inductor designed to meet the demands of modern electronic devices. With an inductance of 68µH, this component offers efficient energy storage and smooth current handling, making it ideal for various power management applications. Measuring 10.3 x 10.5mm, its compact SMD (Surface Mount Device) design ensures easy integration into space-constrained circuits. The inductor boasts robust construction with a ferrite core, ensuring minimal core losses and high reliability. It can handle significant currents with minimal resistance, thereby enhancing overall power efficiency.

Significant Benefits of the Power Inductor Include

  • Ferrite core for low core losses
  • High current handling capability
  • Efficient energy storage and conversion
  • Compact design saves PCB space
  • Reliable performance under various conditions
  • Enhanced power efficiency due to low resistance

Versatile Uses of the CORE MASTER SDI105R-680M, Power Inductor

  • DC-DC Converters
  • Power Supply Modules
  • EMI Filtering
  • Battery-Powered Devices
  • Automotive Electronics
