CORE MASTER WHI0603-R10J-N, INDUCTOR FIXED 0603 100NH SMD

WHI0603-R10J-N
brand logo

HT Part No. HT194456

Mfr. Part No. WHI0603-R10J-N

Manufacturer: CORE MASTER

Technical Documents: Datasheet(datasheets)

10524 - In Stock pcs
Price:
£ 0.097
Units Per Unit Price
1 - 3999 £ 0.097
4000 + £ 0.081
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type SMT
Current - Saturation (Isat) N/A
Pitch None
Technology Wire Wound
Length 1.80mm
Operation Temperature N/A
Inductance 100nH
Tolerance ±5%
Applications General Purpose
Width 1.12mm
Packaging TAPE&REEL
Manufacturer CORE MASTER
Series WHI
Rohs ROHS
Shielding Unshielded
Current Rating 400mA
DC Resistance (DCR) 580m Ohms
Diameter N/A
Height 1.02mm
Package / Case 0603 (1608 Metric)

More Information

The CORE MASTER WHI0603-R10J-N is a fixed inductor featuring a 100nH inductance value, designed for surface-mount applications in a compact 0603 package. This high-quality inductor offers excellent performance with low DC resistance and a high self-resonant frequency, making it an ideal choice for high-frequency applications. Its robust construction ensures durability and reliability, even in demanding environments.

Key Features of the CORE MASTER WHI0603-R10J-N, Power Inductor Fixed

  • 0603 compact SMD package
  • Low DC resistance
  • High self-resonant frequency
  • High current handling capacity
  • What Benefits Does It Offer?
  • Optimised for high-frequency applications
  • Space-saving design suitable for compact circuits
  • Reliable performance in various environmental conditions
  • Enhanced circuit efficiency and stability

Application Areas of the CORE MASTER WHI0603-R10J-N, Power Inductor Fixed

  • RF Circuits and Communication Devices
  • Filtering and Signal Processing
  • Power Management and DC-DC Converters
  • Consumer Electronics and Automotive Systems
