COILMASTER SDS74H-101M-LF, INDUCTOR POWER 100uH 7.6X7.6X4.5mm SMD

SDS74H-101M-LF
brand logo

HT Part No. HT194434

Mfr. Part No. SDS74H-101M-LF

Manufacturer: COILMASTER

Technical Documents: Datasheet(datasheets)

15690 - In Stock pcs
Price:
£ 0.44
Units Per Unit Price
1 - 999 £ 0.44
1000 + £ 0.38
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Technology Wire Wound
Current Rating 990mA
Mounting Type SMT
Current - Saturation (Isat) N/A
Operation Temperature -40°C ~ +125°C
Diameter N/A
Length 7.60mm
Rohs ROHS
Manufacturer COILMASTER
Inductance 100uH
Tolerance ±20%
Width 7.60mm
Height 4.50mm
Packaging TAPE&REEL
Series SDS
Package / Case Non Standard
Pitch None
Shielding Shielded
DC Resistance (DCR) 497m Ohms
Applications Automotive(AEC-Q200)

More Information

The COILMASTER SDS74H-101M-LF is a 100uH power inductor housed in a compact 7.6x7.6x4.5mm SMD package. Designed for efficient power handling, this inductor features a shielded construction to minimize electromagnetic interference. Its low DC resistance enables high current capabilities, making it suitable for demanding applications. Ideal for use in various electronics applications, this component offers a balance of high performance and compact size.

Salient Features and Benefits of Using the COILMASTER SDS74H-101M-LF, Power Inductor

  • Shielded construction
  • Low DC resistance
  • High current capability
  • Reduced EMI
  • Efficient power transfer
  • Compact design

Usage Information of the COILMASTER SDS74H-101M-LF, Power Inductor

  • Power Supplies
  • DC-DC Converters
  • Automotive Electronics
  • Industrial Control Systems
