KEMET MPXV1D0520LR47, INDUCTOR 470NH 12A SHIELDED SMD

MPXV1D0520LR47
brand logo

HT Part No. HT194432

Mfr. Part No. MPXV1D0520LR47

Manufacturer: KEMET

Technical Documents: Datasheet(datasheets)

12459 - In Stock pcs
Price:
£ 0.39
Units Per Unit Price
1 - 3499 £ 0.39
3500 + £ 0.34
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Length 5.30mm
Packaging TAPE&REEL
Manufacturer KEMET
Pitch None
Width 5.00mm
Shielding Shielded
Current Rating 12A
Height 2.00mm
Package / Case Non Standard
Technology Composite
Inductance 470nH
Current - Saturation (Isat) N/A
Series MPXV
Mounting Type SMT
Tolerance ±20%
DC Resistance (DCR) 7.8m Ohms
Applications Automotive(AEC-Q200)
Diameter N/A
Operation Temperature -55°C ~ +155°C
Rohs ROHS

More Information

The KEMET MPXV1D0520LR47 is a high-performance SMD inductor with a 470nH inductance rating designed to support currents up to 12A. This shielded inductor offers excellent efficiency and low core losses, making it ideal for power-sensitive applications. The MPXV1D0520LR47 features a compact design with low-profile packaging, perfect for space-constrained PCBs. Its robust construction ensures durability and reliability, even in harsh operating conditions.

Potential Benefits of Using the KEMET MPXV1D0520LR47, Power Inductor SMD

  • Shielded construction
  • Compact, low-profile design
  • Efficient power handling with low core losses
  • Space-saving design for compact PCB layouts
  • Enhanced durability and reliability in various environments

The KEMET MPXV1D0520LR47, Power Inductor SMD: Wide Application Range

This inductor is an excellent choice for engineers seeking reliable and efficient solutions for modern electronic designs, such as:

  • DC-DC Converters
  • Power Supply Circuits
  • Automotive Electronics
  • Communication Equipment
