COILMASTER SDR43-220M-LF, INDUCTOR POWER 22uH 4.5X4X3.2mm SMD

COILMASTER SDR43-220M-LF, INDUCTOR POWER 22uH 4.5X4X3.2mm SMD
SDR43-220M-LF
brand logo

HT Part No. HT194423

Mfr. Part No. SDR43-220M-LF

Manufacturer: COILMASTER

Technical Documents:

1 - In Stock pcs
Price:
£ 0.21
Units Per Unit Prices
1 - 1499 £ 0.21
1500 + £ 0.19
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series SDR
Technology Wire Wound
Width 4.00mm
Mounting Type SMT
Tolerance ±20%
Length 4.50mm
Height 3.20mm
Manufacturer COILMASTER
Pitch None
Current - Saturation (Isat) N/A
Packaging TAPE&REEL
Package / Case Non Standard
Current Rating 760mA
Applications Automotive(AEC-Q200)
Shielding Shielded
Inductance 22uH
DC Resistance (DCR) 378m Ohms
Diameter N/A
Operation Temperature -40°C ~ +125°C
Rohs ROHS

More Information

The COILMASTER SDR43-220M-LF is a surface-mount inductor designed for power applications. Its compact size of 4.5 x 4 x 3.2mm makes it ideal for space-constrained designs. With an inductance of 22µH, this inductor offers excellent performance in filtering and energy storage applications. Its robust construction ensures reliable operation under high temperatures and mechanical stress.

Possible Advantages of Using the COILMASTER SDR43-220M-LF, Power Inductor SMD

  • SMD (Surface Mount Device) for easy PCB integration
  • High saturation current handling
  • Space-saving design for compact electronic devices
  • High efficiency in energy storage and filtering
  • Durable and reliable under various operating conditions
  • Environmentally friendly with RoHS compliance

The COILMASTER SDR43-220M-LF, Power Inductor SMD: Use Cases

  • Power Supplies
  • DC-DC Converters
  • Portable Electronic Devices
  • LED Drivers
  • Communication Equipment
