BAT54CW-HT - DIODE SCHOTTKY 2*0.2A 30V SOT323 CATHODE

BAT54CW-HT
brand logo

HT Part No. HT299859

Mfr. Part No. BAT54CW-HT

Manufacturer: HOTTECH

Technical Documents: Datasheet(datasheets)

1520 - In Stock pcs
Price:
£ 0.024
Units Per Unit Price
10 - 2999 £ 0.024
3000 + £ 0.016
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case SOT323
Packaging TAPE&REEL
Mounting Type SMT
Applications N/A
Series Schottky Diode
Reverse Recovery Time (Trr) N/A
Manufacturer HOTTECH
Polarity None
Average Rectified Current 200mA (2x200mA)
Diode Configuration Dual Common Cathode
Peak Repetitive Reverse Voltage (VRRM) 30V
Operating Temperature +125°C
Rohs ROHS

More Information

The HOTTECH 449041 is a dual common cathode Schottky diode designed for various electronic applications. This diode features a 30V maximum reverse voltage, offering efficient performance in circuit designs. it is particularly suitable for use in applications requiring high efficiency and fast switching, making it an excellent choice for modern electronic designs.

Unique Advantages of the HOTTECH, 449041, Diode Schottky, Dual Common Cathode, 30V

  • Improved efficiency in power supply circuits
  • Enhanced performance in high-speed switching applications
  • Reduced heat generation due to low forward voltage drop
  • Compact design saves space in circuit layouts

Applications Across Various Fields

  • Power Management Systems
  • Voltage Clamping
  • Reverse Current Protection
  • High-Frequency Rectification in Power Supplies
  • Switching Power Regulators

Technical Insights of the HOTTECH 449041 Diode Schottky

    • High efficiency
    • Low power loss
    • Fast recovery time
    • Low noise generation
