MB510_R1_00001 - DIODE SCHOTTKY 5A 100V DO214AB (SMC) SMT

MB510_R1_00001
brand logo

HT Part No. HT299839

Mfr. Part No. MB510_R1_00001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.18
Units Per Unit Price
2 - 799 £ 0.18
800 + £ 0.16
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Peak Repetitive Reverse Voltage (VRRM) 100V
Manufacturer PANJIT
Series Schottky Rect.
Average Rectified Current 5A
Mounting Type SMT
Operating Temperature -65°C~+175°C
Packaging TAPE&REEL
Diode Configuration Single
Package / Case DO214AB (SMC)
Polarity Cathode
Reverse Recovery Time (Trr) N/A
Applications General Purpose
Rohs ROHS

More Information

The MB510_R1_00001 - SCHOTTKY DIODE is a single, general-purpose diode designed for a variety of applications. With a current rating of 5A and a maximum voltage of 100V, this diode is a robust solution for efficient power management. Its Schottky barrier technology ensures low forward voltage drop and fast switching speed, making it ideal for applications where energy efficiency and response time are critical. This diode features a compact design, which facilitates easy integration into various electronic circuits. Additionally, its low reverse leakage current enhances reliability and performance in demanding conditions.

Special Features & Benefits of MB510_R1_00001 - SCHOTTKY DIODE:

  • Low Forward Voltage Drop: Reduces power loss and improves efficiency.
  • Fast Switching Speed: Ideal for high-frequency applications, reducing signal delay.
  • Compact Design: Allows for space-saving in circuit designs.
  • High Current Capability: Supports up to 5A, suitable for a wide range of power applications.
  • Low Reverse Leakage Current: Enhances reliability and longevity of the diode.

Typical Applications of MB510_R1_00001 - SCHOTTKY DIODE, General Purpose:

  • Power Supplies
  • Voltage Clamping
  • Rectification
  • Switching Circuits
  • Reverse Polarity Protection.
