DSSK28-006BS-TRL - DIODE SCHOTTKY 2*15A 60V TO263AB D2PAK IXYS

DSSK28-006BS-TRL
brand logo

HT Part No. HT299810

Mfr. Part No. DSSK28-006BS-TRL

Manufacturer: IXYS

Technical Documents: Datasheet(datasheets)

19205 - In Stock pcs
Price:
£ 1.51
Units Per Unit Price
1 - 799 £ 1.51
800 + £ 1.37
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Diode Configuration Dual Common Cathode
Reverse Recovery Time (Trr) N/A
Manufacturer IXYS
Applications N/A
Mounting Type SMT
Operating Temperature -55°C~+150°C
Series Schottky Rect.
Average Rectified Current 15A (2x15A)
Peak Repetitive Reverse Voltage (VRRM) 60V
Packaging TAPE&REEL
Package / Case TO263 (D2PAK)
Polarity None
Rohs ROHS

More Information

The IXYS DSSK28-006BS-TRL is a dual common cathode Schottky diode designed for applications demanding high forward current and minimal forward voltage drop. It is ideal for power supplies, DC/DC converters, and other demanding circuits.

Distinct Features of IXYS DSSK28-006BS-TRL IXYS Schottky Diode:

  • Dual common cathode configuration: Simplifies circuit design by allowing the connection of two separate inputs to a single common output.
  • High forward current: Delivers up to 15A per diode, enabling handling of significant currents.
  • Low forward voltage drop: Typically only 0.45V at 15A, minimizing power loss and enhancing efficiency.
  • High reverse voltage: Withstands up to 60V in reverse bias conditions, ensuring robust operation.
  • Surface mount (SMT) package: Facilitates automated assembly for high-volume production and compact PCB designs.
  • RoHS compliant: Meets environmental regulations for restricted substances.

Benefits of IXYS DSSK28-006BS-TRL IXYS Schottky Diode:

  • Improved efficiency: Low forward voltage drop translates to lower power consumption and heat generation.
  • Space-saving design: SMT package minimizes board footprint.
  • Simplified assembly: SMT allows for automated pick-and-place processes.
  • Environmentally friendly: RoHS compliance ensures responsible material use.

Applications Information:

  • Power supplies
  • DC/DC converters
  • Load switching
  • Freewheeling diodes
  • ORing applications.
