VS-10BQ015-M3/5BT - DIODE SCHOTTKY Single 1A 15V DO-214AA SMB

VS-10BQ015-M3/5BT
brand logo

HT Part No. HT299800

Mfr. Part No. VS-10BQ015-M3/5BT

Manufacturer: VISHAY

Technical Documents: Datasheet(datasheets)

12615 - In Stock pcs
Price:
£ 0.056
Units Per Unit Price
5 - 3199 £ 0.056
3200 + £ 0.048
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case DO214AA (SMB)
Manufacturer VISHAY
Polarity Cathode
Peak Repetitive Reverse Voltage (VRRM) 15V
Mounting Type SMT
Applications General Purpose
Rohs ROHS
Diode Configuration Single
Packaging TAPE&REEL
Series Schottky Rect.
Average Rectified Current 1A
Reverse Recovery Time (Trr) N/A
Operating Temperature -55°C~+125°C

More Information

The Vishay VS-10BQ015-M3/5BT is a high-performance surface-mount Schottky diode designed for a variety of general-purpose applications.  It offers several key features that make it ideal for use in space-constrained designs:

Standout Features of VS-10BQ015-M3/5BT - Vishay Schottky Diode, 1A, 15V:

  • Low forward voltage drop (VF) for improved efficiency
  • Fast switching speed for reduced losses
  • High surge current capability for handling unexpected current spikes
  • Excellent thermal performance for reliable operation in various environments.

Potential Benefits of VS-10BQ015-M3/5BT - Schottky Diode, 1A, 15V:

  • Increased efficiency in power conversion circuits by minimizing wasted energy
  • Reduced switching losses for improved performance
  • Enhanced reliability due to its ability to handle surges and operate in high temperatures
  • Space-saving design that allows for more compact circuit boards.

Typical Applications:

  • DC/DC converters: Step up or down voltage levels in power supplies
  • Voltage regulators: Maintain consistent voltage output
  • Load protection circuits: Safeguard circuits from excessive current
  • Power supplies: Provide power to electronic devices.
