MS120_R1_00001 - DIODE SCHOTTKY 1A 200V DO214AC (SMA) SMT

MS120_R1_00001
brand logo

HT Part No. HT299791

Mfr. Part No. MS120_R1_00001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

6875 - In Stock pcs
Price:
£ 0.089
Units Per Unit Price
5 - 1799 £ 0.089
1800 + £ 0.073
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Operating Temperature -65°C~+175°C
Reverse Recovery Time (Trr) N/A
Diode Configuration Single
Peak Repetitive Reverse Voltage (VRRM) 200V
Series Schottky Rect.
Package / Case DO214AC (SMA)
Applications General Purpose
Rohs ROHS
Manufacturer PANJIT
Mounting Type SMT
Polarity Cathode
Average Rectified Current 1A
Packaging TAPE&REEL

More Information

The MS120_R1_00001 is a high-performance, surface-mount Schottky diode from PANJIT International. This compact and versatile component offers a perfect blend of functionality and efficiency, making it ideal for various electronic applications.

Standout Features of MS120_R1_00001 – PANJIT Schottky Diode:

  • High Forward Current: Handles up to 1A of continuous current, ensuring smooth operation in demanding circuits.
  • 200V Reverse Voltage: Withstands high voltage spikes, providing robust protection for sensitive components.
  • Low Forward Voltage Drop: Minimizes power loss and improves overall circuit efficiency.
  • Surface Mount (SMT) Package: Enables space-saving designs and simplifies high-volume PCB assembly.

Potential Benefits of MS120_R1_00001 – PANJIT Schottky Diode, 1A, 200V:

  • Enhanced System Reliability: Protects circuits from voltage transients and ensures stable operation.
  • Improved Efficiency: Lowers power consumption and heat generation for better thermal performance.
  • Compact Design Flexibility: Enables the creation of smaller, lighter electronic devices.
  • Cost-Effective Solution: Offers excellent value for a wide range of applications.

Applications Information:

  • Power supply rectification
  • Voltage clamping and transient suppression
  • Load switching and polarity protection
  • Logic circuits and signal routing.
