D1FS4-5053 - DIODE SCHOTTKY 1.1A 40V DO214AC (SMA) SMT

D1FS4-5053
brand logo

HT Part No. HT299703

Mfr. Part No. D1FS4-5053

Manufacturer: SHINDENGEN

Technical Documents: Datasheet(datasheets)

5804 - In Stock pcs
Price:
£ 0.11
Units Per Unit Price
2 - 1999 £ 0.11
2000 + £ 0.097
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series Schottky Diode
Average Rectified Current 1.1A
Applications Automotive(AEC-Q101)
Rohs ROHS
Mounting Type SMT
Packaging TAPE&REEL
Diode Configuration Single
Polarity Cathode
Peak Repetitive Reverse Voltage (VRRM) 40V
Manufacturer SHINDENGEN
Package / Case DO214AC (SMA)
Reverse Recovery Time (Trr) N/A
Operating Temperature +150°C

More Information

The Shindengen D1FS4-5053 is a 1.1A, 40V Schottky diode ideal for automotive applications that require high reliability and performance under demanding conditions.  This surface-mount (SMT) diode is AEC-Q101 qualified, ensuring it meets the stringent quality standards for automotive components.

Distinct Features of D1FS4-5053 - SHINDENGEN Schottky Diode:

  • AEC-Q101 qualified: Guarantees exceptional reliability in harsh automotive environments.
  • High forward current (1.1A): Enables handling of larger currents.
  • Low forward voltage (VF): Reduces power loss and improves efficiency.
  • Fast switching speed: Supports applications requiring rapid switching.
  • Excellent ESD protection: Safeguards against electrostatic discharge damage.
  • Surface-mount (SMT) package: Saves space and simplifies PCB assembly.

Benefits for Potential Users:

  • AEC-Q101 qualification ensures dependable operation in automotive applications.
  • Low forward voltage minimizes power loss and enhances efficiency.
  • Fast switching speed makes it suitable for high-speed switching circuits.
  • Excellent ESD protection safeguards against electrostatic discharge damage.
  • SMT package offers space-saving benefits and simplifies PCB assembly.

Where is D1FS4-5053 - SHINDENGEN Schottky DiodeUsed?

  • Load switching and protection circuits
  • DC/DC converters
  • Power supplies
  • LED drivers
  • Automotive electronics.
