RB751S40_R1_00001 - DIODE SCHOTTKY 300mA 40V SOD523 SMT

RB751S40_R1_00001
brand logo

HT Part No. HT299692

Mfr. Part No. RB751S40_R1_00001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

1710 - In Stock pcs
Price:
£ 0.040
Units Per Unit Price
10 - 4999 £ 0.040
5000 + £ 0.032
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Reverse Recovery Time (Trr) N/A
Polarity Cathode
Mounting Type SMT
Package / Case SOD523
Rohs ROHS
Manufacturer PANJIT
Series Schottky Diode
Applications General Purpose
Operating Temperature -55°C~+125°C
Packaging TAPE&REEL
Diode Configuration Single
Average Rectified Current 300mA
Peak Repetitive Reverse Voltage (VRRM) 40V

More Information

The RB751S40_R1_00001 is a high-quality, surface-mount Schottky diode from PANJIT. It offers a forward current rating of 30mA and a reverse voltage rating of 40V, making it suitable for a wide range of general-purpose applications.

Distinguished Features of RB751S40_R1_00001 Schottky Diode:

  • Low forward voltage: Ensures minimal power loss during conduction.
  • Fast switching speed: Enables efficient operation in high-frequency circuits.
  • Small SMT package: Saves space on PCBs and simplifies assembly.
  • High reliability: Proven performance for long-lasting applications.

What are the Benefits of Using RB751S40_R1_00001 - PANJIT Schottky Diode:

  • Improved efficiency in circuits with frequent switching events.
  • Reduced board size and weight due to the compact SMT form factor.
  • Cost-effective solution for various general-purpose applications.

Application Areas of RB751S40_R1_00001 - PANJIT Schottky Diode, 30mA, 40V:

  • Voltage clamping and protection circuits.
  • Level shifting and signal gating applications.
  • High-speed rectification in power supplies and converters.
  • Detector circuits and logic level conversion.
