BAT85-DC - DIODE SCHOTTKY 200MA 30V THT DO35

BAT85-DC
brand logo

HT Part No. HT299642

Mfr. Part No. BAT85-DC

Manufacturer: DC CORP.

Technical Documents:

5 - In Stock pcs
Price:
£ 0.032
Units Per Unit Prices
10 - 4999 £ 0.032
5000 + £ 0.032
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Peak Repetitive Reverse Voltage (VRRM) 30V
Package / Case DO35
Applications General Purpose
Diode Configuration Single
Average Rectified Current 200mA
Manufacturer DC CORP.
Reverse Recovery Time (Trr) N/A
Packaging AMMO PACK
Series Schottky Rect.
Mounting Type SMT
Polarity Cathode
Operating Temperature -55°C~+125°C
Rohs ROHS

More Information

The BAT85-DC is a high-performance, surface-mount Schottky diode from DC CORP., ideal for various electronic applications requiring efficient and reliable switching.

Distinct Features of BAT85-DC - DC CORP. Schottky Diode, 200mA, 30V:

  • Low forward voltage drop: This diode boasts a low forward voltage drop, minimizing power loss during conduction.
  • Fast switching speed: With a rapid switching time, the BAT85-DC is perfect for high-frequency circuits.
  • Small SMT package: The compact Surface-Mount Technology (SMT) design saves valuable space on PCBs.
  • 30V reverse voltage rating: This diode can withstand up to 30V in reverse bias, ensuring robust operation.

Benefits of BAT85-DC to Potential Users:

  • Improved efficiency: Low forward voltage drop translates to lower power consumption and heat generation.
  • Reduced signal distortion: Fast switching minimizes signal distortion in high-speed applications.
  • Simplified PCB design: The SMT package allows for smaller, denser PCBs.
  • Enhanced reliability: The 30V reverse voltage rating safeguards the diode against voltage spikes.

Applications Information:

  • Voltage clamping and protection circuits
  • High-speed switching applications
  • Logic-level signal routing
  • Portable and battery-powered devices.
