PANJIT BAT42WR100001, DIODE SCHOTTKY 200mA 30V SOD123 SMT

BAT42W_R1_00001
brand logo

HT Part No. HT299641

Mfr. Part No. BAT42W_R1_00001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

3510 - In Stock pcs
Price:
£ 0.048
Units Per Unit Price
10 - 2999 £ 0.048
3000 + £ 0.040
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case SOD123
Polarity Cathode
Reverse Recovery Time (Trr) N/A
Manufacturer PANJIT
Diode Configuration Single
Operating Temperature -55°C~+125°C
Average Rectified Current 200mA
Applications General Purpose
Series Schottky Diode
Mounting Type SMT
Peak Repetitive Reverse Voltage (VRRM) 30V
Rohs ROHS
Packaging TAPE&REEL

More Information

The PANJIT BAT42WR100001 is a Schottky diode designed for low-power applications. It has a current rating of 200mA and a voltage rating of 30V and is encased in a compact SOD123 surface-mount technology (SMT) package. This diode is known for its low forward voltage drop and fast switching speed, making it perfect for high-frequency applications.

Usage Information of the PANJIT BAT42WR100001, Schottky Diode

  • Power Supply Circuits: Used for rectification and voltage regulation.
  • Switching Power Supplies: Ideal for high-frequency switching.
  • Protection Circuits: Provides reverse polarity protection.
  • RF Applications: Suitable for radio frequency and microwave applications.
  • Solar Panels: Utilised in photovoltaic systems for efficiency improvement.
  • Battery Chargers: Enhances performance in charging circuits.

What Are the Possible Advantages of Using the PANJIT BAT42WR100001, Schottky Diode?

  • Low forward voltage drop reduces power loss and improves efficiency.
  • Fast switching speed enhances performance in high-frequency applications.
  • The SOD123 SMT package allows space-saving in circuit designs.
  • Low reverse leakage current ensures stability and reliability over time.
  • Wide operating temperature range ensures functionality in various environments.
