PANJIT 1N5822AY10001, DIODE SCHOTTKY 3A 40V DO-201AD

1N5822_AY_10001
brand logo

HT Part No. HT299631

Mfr. Part No. 1N5822_AY_10001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

88924 - In Stock pcs
Price:
£ 0.089
Units Per Unit Price
1 - 1249 £ 0.089
1250 + £ 0.073
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Packaging AMMO PACK
Reverse Recovery Time (Trr) N/A
Operating Temperature -55°C~+150°C
Series Schottky Rect.
Applications General Purpose
Diode Configuration Single
Package / Case DO201 (DO27)
Polarity Cathode
Rohs ROHS
Manufacturer PANJIT
Mounting Type THT
Average Rectified Current 3A
Peak Repetitive Reverse Voltage (VRRM) 40V

More Information

The PANJIT 1N5822AY10001 is a Schottky diode designed for applications requiring fast switching and low forward voltage drop. Rated at 3A and 40V, it features a DO-201AD package, ensuring efficient performance in rectification and protection circuits. Schottky diodes are widely recognised for their efficiency and low power loss, making them ideal for various electronic applications.

Standout Features and Benefits of Using the PANJIT 1N5822AY10001, Schottky Diode

  • Fast Switching Speed: Ensures rapid response in high-frequency applications.
  • Low Forward Voltage Drop: Minimises power loss and improves efficiency.
  • Low Reverse Leakage Current: Reduces energy loss and improves overall performance.
  • Energy Efficiency: Low forward voltage drop leads to lower power consumption.
  • Enhanced Performance: Fast switching speeds improve the performance of high-frequency circuits.
  • Durability: Robust packaging and high current capability ensure long-term reliability.
  • Reduced Heat Generation: Lower power dissipation minimises the need for extensive cooling solutions.

Application Information of the PANJIT 1N5822AY10001, Schottky Diode

  • Power Supply Rectification: Converts AC to DC efficiently in power supply units.
  • DC-DC Converters: Improves the efficiency of voltage regulation in electronic devices.
  • Freewheeling Diodes: Protects inductive loads by providing a path for current during switching.
  • Reverse Voltage Protection: Prevents damage to sensitive components by blocking reverse currents.
  • Solar Panel Systems: Enhances energy conversion efficiency and protects against reverse currents.
