PANJIT SK36R100001, DIODE SCHOTTKY 3A 60V DO-214AB SMC

SK36_R1_00001
brand logo

HT Part No. HT299600

Mfr. Part No. SK36_R1_00001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

132168 - In Stock pcs
Price:
£ 0.089
Units Per Unit Price
5 - 799 £ 0.089
800 + £ 0.073
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Diode Configuration Single
Package / Case DO214AB (SMC)
Reverse Recovery Time (Trr) N/A
Applications General Purpose
Mounting Type SMT
Peak Repetitive Reverse Voltage (VRRM) 60V
Manufacturer PANJIT
Packaging TAPE&REEL
Series Schottky Rect.
Polarity Cathode
Average Rectified Current 3A
Operating Temperature -55°C~+150°C
Rohs ROHS

More Information

The PANJIT SK36R100001 is a Schottky diode designed for efficient rectification in electronic circuits. It boasts a current rating of 3A and a voltage rating of 60V and is housed in a DO-214AB (SMC) package. This diode leverages Schottky barrier technology to provide low forward voltage drop and fast switching capabilities, making it ideal for high-frequency applications and power management tasks.

What Are the Potential Advantages of the PANJIT SK36R100001, Schottky Diode?

  • Low Forward Voltage Drop
  • Fast Switching Speed
  • Highly Reliable
  • Exceptional Thermal Stability
  • Increased Efficiency
  • Compact Design
  • Enhanced Performance
  • Cost-Effective Solution

Application Versatility of the PANJIT SK36R100001, Schottky Diode

  • Power Supplies: Used in AC/DC and DC/DC converters for efficient power rectification.
  • Switching Regulators: Enhances performance in voltage regulation circuits.
  • Freewheeling Diodes: Prevents voltage spikes in inductive loads.
  • Reverse Battery Protection: Safeguards circuits against reverse voltage conditions.
  • Solar Panels: Improves energy conversion efficiency in photovoltaic systems.
  • Motor Drives: Ensures smooth operation and protection in motor control circuits.
  • Consumer Electronics: Widely utilised in devices requiring efficient power management.
