SR34_R2_00001 - DIODE SCHOTTKY 3A 40V DO214AA (SMB) SMT

SR34_R2_00001
brand logo

HT Part No. HT299576

Mfr. Part No. SR34_R2_00001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

13966 - In Stock pcs
Price:
£ 0.10
Units Per Unit Price
2 - 2999 £ 0.10
3000 + £ 0.089
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Polarity Cathode
Peak Repetitive Reverse Voltage (VRRM) 40V
Packaging TAPE&REEL
Series Schottky Rect.
Diode Configuration Single
Mounting Type SMT
Manufacturer PANJIT
Average Rectified Current 3A
Operating Temperature -55°C~+150°C
Package / Case DO214AA (SMB)
Reverse Recovery Time (Trr) N/A
Applications General Purpose
Rohs ROHS

More Information

The SR34_R2_00001 is a high-performance, 3A forward current, 40V reverse voltage Schottky diode in a compact, surface-mount SMT package. It offers distinct features like low forward voltage drop, fast switching speed, and high surge current capability, resulting in superior efficiency and faster signal processing. This general-purpose diode is ideal for various applications, including:

Typical Uses of SR34_R2_00001 - PANJIT Schottky Diode, 3A, 40V:

  • Voltage clamping in power supplies and DC-DC converters
  • Load switching and polarity protection circuits
  • High-speed signal routing and logic circuits
  • Power over Ethernet (PoE) applications.
