PANJIT SB160AY10001, DIODE SCHOTTKY 1A 60V DO-41 PANJIT

SB160_AY_10001
brand logo

HT Part No. HT299510

Mfr. Part No. SB160_AY_10001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

164926 - In Stock pcs
Price:
£ 0.032
Units Per Unit Price
2 - 4999 £ 0.032
5000 + £ 0.024
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case DO41
Average Rectified Current 1A
Reverse Recovery Time (Trr) N/A
Applications General Purpose
Peak Repetitive Reverse Voltage (VRRM) 60V
Operating Temperature -55°C~+150°C
Rohs ROHS
Manufacturer PANJIT
Mounting Type THT
Packaging AMMO PACK
Series Schottky Rect.
Diode Configuration Single
Polarity Cathode

More Information

The PANJIT SB160AY10001 is a Schottky diode designed for high-efficiency rectification in electronic circuits. It features a 1-ampere current rating and a 60-volt reverse voltage capability. This diode is encapsulated in the DO-41 package, which provides durability and ease of installation. Schottky diodes are well-known for their low forward voltage drop and fast-switching, making them ideal for applications requiring efficient power management.

Standout Features and Benefits of Using the PANJIT SB160AY10001, Schottky Diode

  • Reduces power loss and increases efficiency.
  • Ideal for high-frequency applications.
  • Ensures reliability in various voltage conditions.
  • Low forward voltage drop minimises energy loss.
  • Fast switching speeds support high-frequency operations.
  • The DO-41 package offers robust protection.
  • Suitable for various voltage and current requirements.
  • Efficient power management reduces operational costs.

Usage Information of the PANJIT SB160AY10001, Schottky Diode

  • Power Supplies: Enhances efficiency in AC to DC conversion.
  • Switching Power Supplies: Improves performance in SMPS circuits.
  • Solar Panels: Assists in preventing backflow of current.
  • Battery Chargers: Ensures efficient charging cycles.
  • General Rectification: Suitable for diverse rectification needs in electronic circuits.
