PANJIT UF106GAY10001, DIODE U.FAST SINGLE 1A 600V DO41 THT

UF106G_AY_10001
brand logo

HT Part No. HT295139

Mfr. Part No. UF106G_AY_10001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

4945 - In Stock pcs
Price:
£ 0.056
Units Per Unit Price
1 - 4999 £ 0.056
5000 + £ 0.048
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Applications General Purpose
Mounting Type THT
Reverse Recovery Time (Trr) 100ns
Current - Average (Each Diode) 1A
Case Material Plastic
Rohs ROHS
Series Glass Passivated Ultra Fast Recovery
Diode Configuration Single
Package / Case DO41
Voltage (VRRM) 600V
Manufacturer PANJIT
Polarity Cathode
Operating Temperature -55°C~+150°C
Packaging AMMO PACK

More Information

The PANJIT UF106GAY10001 is a high-performance, ultra-fast recovery diode designed for efficient rectification applications. It is a single ultra-fast recovery diode with a standard current rating of 1A and a peak reverse voltage of 600V, packaged in a DO-41 THT (Through-Hole Technology) form factor.

Unique Advantages of Using the Recovery Diode

  • Enhanced efficiency in rectification applications
  • Reduced power losses due to low forward voltage drop
  • Suitable for high-voltage applications
  • Reliable performance in demanding environments
  • Easy to implement in through-hole PCB designs
  • Capable of handling high surge currents, improving durability

Application Areas of the PANJIT UF106GAY10001, Ultra-Fast Recovery Diode

This diode is ideal for use in various electronic circuits requiring efficient and reliable rectification, making it a versatile component for various electronic applications, such as:

  • Power Supply Rectification
  • Switching Power Supplies
  • Inverters
  • Freewheeling Diodes
  • Snubber Circuits
  • High-Frequency Rectification
