PANJIT US1GR100001, DIODE U.FAST SINGLE 1A 400V DO214AC (SMA) SMT

US1G_R1_00001
brand logo

HT Part No. HT295128

Mfr. Part No. US1G_R1_00001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

4090 - In Stock pcs
Price:
£ 0.073
Units Per Unit Price
5 - 1799 £ 0.073
1800 + £ 0.056
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type SMT
Current - Average (Each Diode) 1A
Reverse Recovery Time (Trr) 50ns
Applications General Purpose
Series Ultra Fast Recovery
Polarity Cathode
Packaging TAPE&REEL
Diode Configuration Single
Case Material Plastic
Operating Temperature -55°C~+150°C
Rohs ROHS
Manufacturer PANJIT
Package / Case DO214AC (SMA)
Voltage (VRRM) 400V

More Information

The PANJIT US1GR100001 is an ultra-fast recovery diode that is a single surface-mount technology (SMT) component. It operates with a current capacity of 1A and a voltage rating of 400V and is packaged in a DO214AC (SMA) form factor.

Possible Benefits of Using the PANJIT US1GR100001, Ultra-Fast Recovery Diode

  • Efficiency: The ultra-fast recovery time and low forward voltage drop contribute to higher efficiency in power conversion applications.
  • Compact Size: The DO214AC (SMA) package offers a compact form factor suitable for high-density circuit boards.
  • Reliability: High surge current capability and low leakage current ensure stable and reliable performance.
  • Versatility: Suitable for various applications due to its high voltage and current ratings.

Application Versatility of the PANJIT US1GR100001, Ultra-Fast Recovery Diode

The PANJIT US1GR100001 is an ideal choice for applications requiring fast switching and efficient power conversion, providing robust performance in demanding electronic environments, such as:

  • Power Supplies
  • Switching Power Supplies
  • Inverters
  • Freewheeling Diodes
  • High-Frequency Rectification
  • Snubber Circuits
  • Polarity Protection Diodes in Various Electronic Circuits
