PULSE HX5004ENL, TRASNFORMER PULSE XFMR 1 CT:1CT TX/RX 350UH

HX5004ENL
brand logo

HT Part No. HT190845

Mfr. Part No. HX5004ENL

Manufacturer: PULSE

Technical Documents: Datasheet(datasheets)

20 - In Stock pcs
Price:
£ 15.12
Units Per Unit Price
1 - 24 £ 15.12
25 + £ 14.13
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Transformer Type LAN 10/100/1000 Base-T
Manufacturer PULSE
Inductance 350uH
Turns Ratio - PrimarySecondary 1CT:1CT Transmitter, 1CT:1CT Receiver
Number of Positions or Pins (Grid) 24Pins
Rohs ROHS
Model HX5004
Mounting Type SMT
ET (Volt-Time) N/A
Operating Temperature -40°C~+85°C
Packaging TUBE

More Information

The PULSE HX5004ENL is a high-performance Ethernet magnetics module designed to ensure reliable data transmission in networking applications. It integrates transformers and common-mode chokes to minimise electromagnetic interference (EMI), enhancing signal integrity over Ethernet connections.

Unique Features and Benefits of Using the PULSE HX5004ENL, Ethernet Magnetics Module

  • Compact footprint suitable for space-constrained applications.
  • IEEE 802.3 is compliant with Ethernet standards.
  • RoHS-compliant, ensuring environmental sustainability.
  • Enhanced EMI suppression for improved signal quality.
  • High reliability and durability for extended product lifespan.
  • Ensures stable and efficient data transmission.
  • Reduces EMI, minimising potential network disruptions.
  • Compact design saves PCB space and simplifies integration.
  • Compliance with industry standards ensures compatibility and reliability.
  • Longevity and robustness reduce maintenance costs.

Where Can You Employ the PULSE HX5004ENL, Ethernet Magnetics Module?

  • Ethernet Switches and Routers
  • Industrial Automation and Control Systems
  • Network Interface Cards (NICs)
  • Data Centers and Telecommunications Equipment
  • Consumer Electronics for Reliable Networking
