TPS22969DNYR - IC-22969 LOAD SWITCH 6A 8WSON

TPS22969DNYR
brand logo

HT Part No. HT272918

Mfr. Part No. TPS22969DNYR

Manufacturer: TEXAS

Technical Documents: Datasheet(datasheets)

2983 - In Stock pcs
Price:
£ 0.53
Units Per Unit Price
1 - 2999 £ 0.53
3000 + £ 0.48
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Features 5.5-V, 6-A, 4.4-m? On-Resistance Load Switch
Manufacturer TEXAS
Mounting Type SMT
Package / Case PowerWDFN-8
Output Type High Side
Supply Voltage 0.8V to 5.5V
Output Current (Max) 6A
Number Of Channelss 1 Channel
Operating Temperature -40°C~+125°C
Rohs ROHS
Packaging TAPE&REEL

More Information

The TEXAS TPS22969DNYR is a high-performance load switch designed to manage power distribution in electronic devices. It is encapsulated in a compact 8-WSON package, ideal for space-constrained applications. It is an integrated load switch with a low ON resistance, enabling efficient power control for various electronic circuits.

Potential Benefits of the TEXAS TPS22969DNYR Load Switch

  • Enhances power efficiency by minimising power loss
  • Protects circuits with built-in thermal shutdown and reverse current blocking
  • Ensures reliable operation with UVLO and controlled rise time
  • Saves board space with its compact design

Versatile Uses of the TEXAS TPS22969DNYR, Load Switch IC

The TPS22969DNYR load switch offers robust power management solutions, making it ideal for applications requiring high efficiency and reliability in a small footprint, including:

  • Portable and battery-powered devices
  • Consumer electronics such as smartphones and tablets
  • Power management in laptops and notebooks
  • Industrial and medical equipment requiring efficient power control

Special Features of the Load Switch IC Include

  • Supports up to 6A continuous current
  • Integrated thermal shutdown
  • Controlled rise time and quick shutdown
  • Reverse current protection
  • UVLO (Under-Voltage Lockout)
