ADE7953ACPZ - IC-7953 ENERGY METERING 1PHASE 28LFCSP ANALOGDEVIC

ADE7953ACPZ
brand logo

HT Part No. HT272846

Mfr. Part No. ADE7953ACPZ

Manufacturer: ANALOGDEVICES

Technical Documents: Datasheet(datasheets)

998 - In Stock pcs
Price:
£ 3.23
Units Per Unit Price
1 - 4999 £ 3.23
5000 + £ 2.94
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Features Single Phase, Multifunctional Metering IC
Package / Case WFQFN28 (5x5)
Mounting Type SMT
Mesaurement Error %0.1
Active Measurement Bandwidth 1.23kHz
Supply Voltage 3V to 3.6V
Rohs ROHS
Manufacturer ANALOGDEVICES
Supply Current (Typ) 7mA
Output Voltage(HIGH/LOW) 3.0V/0.4V
Operating Temperature -40°C~+85°C
Packaging TAPE&REEL

More Information

The ANALOGDEVICES ADE7953ACPZ is a high-accuracy electrical energy metering IC designed for single-phase metering applications. This integrated circuit measures real, reactive, and apparent energy, as well as RMS values of voltage and current. To enhance performance and reliability, the ADE7953 features a high-speed data communication interface and an integrated temperature sensor.

Special Features of the ANALOGDEVICES ADE7953ACPZ, Energy Metering IC

  • High-accuracy metering of real, reactive, and apparent energy
  • RMS measurement of voltage and current
  • High-speed data communication interface
  • Integrated temperature sensor for enhanced reliability
  • Low power consumption and small form factor (28-LFCSP package)

What Benefits Do You Get?

  • Provides accurate and reliable energy measurement for various applications
  • Compact design saves space in electronic devices
  • Low power consumption reduces overall energy usage
  • High-speed data communication enables real-time monitoring and control
  • Integrated temperature sensor ensures consistent performance in varying conditions

Application Versatility of the ANALOGDEVICES ADE7953ACPZ, Energy Metering IC

The ADE7953ACPZ by Analog Devices is a versatile and efficient solution for modern energy metering needs, including:

  • Single-phase energy meters for residential, commercial, and industrial use
  • Smart meters for real-time energy monitoring
  • Power quality monitoring systems
  • Load monitoring and management systems
  • Energy-saving devices and solutions
