PIHER PT15NH02-104A2020-S, TRIMPOT CARBON H 15mm 100K ±20% OVAL

PT15NH02-104A2020-S
brand logo

HT Part No. HT193538

Mfr. Part No. PT15NH02-104A2020-S

Manufacturer: PIHER

Technical Documents:

387 - In Stock pcs
Price:
£ 0.23
Units Per Unit Prices
1 - 399 £ 0.23
400 + £ 0.20
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Shaft Without Shaft
Packaging BULK&BOX
Resistance Value 100K Ohms
Tolerance ±20%
Keyword karbon trimpot, japon tip trimpot, kombi trimpot, kombi kart trimpot
Manufacturer PIHER
Size 15mm
Adjust Method Horizontal
Rohs ROHS
Mounting Type THT
Taper Linear
Mounting method Vertical
Number of Turn Single Turn
Series PT15
Rotors Oval
Temperature Coefficient ±300 ppm/°C

More Information

The PIHER PT15NH02-104A2020-S is a high-quality, adjustable resistor with a carbon element and a 15mm oval-shaped housing. This trimmer potentiometer, typically referred to as a "trimpot," features a resistance of 100K ohms with a tolerance of ±20%. It's designed to fine-tune electronic circuits to achieve optimal performance. This trimpot is a versatile and reliable component for precise electronic adjustments, ensuring enhanced device performance and longevity.

Impressive Features and Benefits of Using the PIHER PT15NH02-104A2020-S, Oval-Shaped, Trimmer Potentiometer

  • Carbon element for stable performance
  • 15mm oval housing, ideal for space-constrained applications
  • Horizontal mounting style
  • Enables fine-tuning of circuit parameters for optimal functionality
  • Durable design suitable for various environmental conditions
  • Compact size fits into tight spaces, maximizing PCB real estate

Application Areas of the PIHER PT15NH02-104A2020-S, Oval-Shaped, Trimmer Potentiometer

  • Used in the calibration of electronic devices
  • Suitable for use in audio equipment for volume and tone control
  • Ideal for adjusting frequency in oscillators and filters in communication equipment
