PIHER PT15NV17-103A2020-EP03-S, TRIMPOT CARBON V 15MM 10K 20% OVAL 3P DETENT

PT15NV17-103A2020-EP03-S
brand logo

HT Part No. HT193516

Mfr. Part No. PT15NV17-103A2020-EP03-S

Manufacturer: PIHER

Technical Documents: Datasheet(datasheets)

5349 - In Stock pcs
Price:
£ 0.32
Units Per Unit Price
1 - 399 £ 0.32
400 + £ 0.28
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type THT
Number of Turn Single Turn
Resistance Value 10K Ohms
Adjust Method Vertical
Shaft Without Shaft
Rotors Oval
Tolerance ±20%
Temperature Coefficient ±300 ppm/°C
Manufacturer PIHER
Series PT15
Size 15mm
Keyword karbon trimpot, japon tip trimpot, kombi trimpot, kombi kart trimpot
Taper Linear
Mounting method Horizontal
Rohs ROHS
Packaging BULK&BOX

More Information

The PIHER PT15NV17-103A2020-EP03-S is a high-quality trimmer potentiometer, often referred to as a trimpot, designed for precision adjustment in electronic circuits. It features a 10K ohm resistance with a tolerance of ±20%, providing reliable and accurate tuning. This carbon element potentiometer measures 15mm in size and has an oval shape with three pins, ensuring versatile integration into various electronic applications. The inclusion of a detent mechanism facilitates stable and repeatable settings, making it ideal for fine-tuning purposes.

Salient Features and Benefits of Using the PIHER PT15NV17-103A2020-EP03-S, Trimmer Potentiometer

  • Detent mechanism: For stable adjustments
  • Precision: Allows for accurate calibration and tuning in circuits.
  • Stability: Detent feature ensures consistent settings over time.
  • Versatility: Suitable for various electronic applications due to its standard size and pin configuration.

Application Versatility of the PIHER PT15NV17-103A2020-EP03-S, Trimmer Potentiometer

The PIHER PT15NV17-103A2020-EP03-S trimpot is an essential component for achieving precise control and stability in electronic designs:

  • Electronic circuits: Utilised for tuning and calibration.
  • Audio equipment: For volume and tone adjustments.
  • Industrial controls: Precise adjustment in control systems.
  • Consumer electronics: Fine-tuning performance parameters.
