PIHER PT15GV12-104A2020-S, TRIMPOT CARBON V 12.5MM 104 20% OVAL

PT15GV12-104A2020-S
brand logo

HT Part No. HT193480

Mfr. Part No. PT15GV12-104A2020-S

Manufacturer: PIHER

Technical Documents:

2 - In Stock pcs
Price:
£ 0.23
Units Per Unit Prices
1 - 399 £ 0.23
400 + £ 0.19
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Resistance Value 100K Ohms
Number of Turn Single Turn
Mounting Type THT
Tolerance ±20%
Shaft Without Shaft
Rohs ROHS
Packaging BULK&BOX
Size 15mm
Taper Linear
Rotors Oval
Keyword karbon trimpot, japon tip trimpot, kombi trimpot, kombi kart trimpot
Manufacturer PIHER
Series PT15
Mounting method Horizontal
Adjust Method Vertical
Temperature Coefficient ±300 ppm/°C

More Information

The PIHER PT15GV12-104A2020-S is a trim pot carbon variable resistor designed for precision and reliability in various electronic applications. This model features a 12.5mm size, a resistance value of 100k ohms, and a tolerance of ±20%. The oval shape of the trim pot allows for easy adjustment and integration into compact spaces.

Salient Features and Benefits Offered By the  PIHER PT15GV12-104A2020-S, Trimmer Potentiometer

  • Type: Trimpot carbon variable resistor
  • Adjustment: Top adjustment for easy access
  • Precision: Provides accurate resistance adjustments
  • Compact Design: Fits into limited space applications
  • Reliability: Durable construction ensures long-lasting performance
  • Ease of Use: Top adjustment allows for straightforward tuning and calibration

Usage Information of the PIHER PT15GV12-104A2020-S, Trimmer Potentiometer

The PIHER PT15GV12-104A2020-S trimpot is a versatile and reliable component for precision electronic applications, such as:

  • Circuit Tuning: Used in fine-tuning of circuits for optimal performance
  • Calibration: Essential in calibrating electronic devices
  • Signal Processing: Ideal for adjusting signal levels in audio and other signal-processing equipment
  • Voltage Regulation: Used in voltage regulators to set precise output levels
