PIHER PT15LH05-105A2020-S, TRIMPOT CARBON H 15mm 1M ±20% SCREWDR.

PT15LH05-105A2020-S
brand logo

HT Part No. HT193471

Mfr. Part No. PT15LH05-105A2020-S

Manufacturer: PIHER

Technical Documents: Datasheet(datasheets)

2000 - In Stock pcs
Price:
£ 0.31
Units Per Unit Price
1 - 399 £ 0.31
400 + £ 0.27
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Number of Turn Single Turn
Rotors Screwdriver
Shaft Without Shaft
Taper Linear
Mounting method Vertical
Temperature Coefficient ±300 ppm/°C
Keyword karbon trimpot, japon tip trimpot, kombi trimpot, kombi kart trimpot
Manufacturer PIHER
Series PT15
Size 15mm
Mounting Type THT
Resistance Value 1M Ohms
Adjust Method Horizontal
Tolerance ±20%
Rohs ROHS
Packaging BULK&BOX

More Information

The PIHER PT15LH05-105A2020-S is a 15mm trimmer potentiometer, typically referred to as a trimpot, designed for fine-tuning and adjusting resistance in electronic circuits. It features a carbon element and provides a resistance value of 1MΩ (megaohm) with a tolerance of ±20%. The adjustment is made via a top screw, ensuring precise control over the resistance setting.

Potential Benefits and Features of the PIHER PT15LH05-105A2020-S, Trimmer Potentiometer

  • Carbon resistive element
  • Top adjustment screw for easy calibration
  • Horizontal mount
  • Precise resistance adjustment helps in fine-tuning circuits
  • Compact size suitable for space-constrained designs
  • Easy to adjust with a standard screwdriver
  • Reliable performance with a wide tolerance range
  • Ideal for both prototypes and final products

Application Areas of the PIHER PT15LH05-105A2020-S, Trimmer Potentiometer

  • Calibration of electronic circuits
  • Volume and tone control in audio devices
  • Adjusting reference voltages in power supplies
  • Tuning oscillators in communication equipment
  • Setting thresholds in sensors and measurement instruments
