PT10MH01-225A2020-W - TRIMPOT CARBON H 10MM 2M2 ALYAN WUJIN SPIKE

PT10MH01-225A2020-W
brand logo

HT Part No. HT193396

Mfr. Part No. PT10MH01-225A2020-W

Manufacturer: WUJIN SPIKE

Technical Documents: Datasheet(datasheets)

320 - In Stock pcs
Price:
£ 0.11
Units Per Unit Price
1 - 999 £ 0.11
1000 + £ 0.097
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type THT
Adjust Method Horizontal
Rohs ROHS
Rotors Allen
Mounting method Vertical
Number of Turn Single Turn
Manufacturer WUJIN SPIKE
Series PT10
Shaft Without Shaft
Packaging BULK&BOX
Resistance Value 2.2M Ohms
Temperature Coefficient ±300 ppm/°C
Size 10mm
Taper Linear
Tolerance ±20%
Keyword karbon trimpot, japon tip trimpot, kombi trimpot, kombi kart trimpot

More Information

The PT10MH01-225A2020-W is a high-performance, single-turn trimmer potentiometer made by WUJIN.  It is designed for space-saving integration into printed circuit boards (PCBs) due to its compact 10mm size and vertical mounting style.  This trimmer offers precise resistance adjustment in various electronic circuits with its 2.2MΩ resistance and ±20% tolerance.

Distinct Features of PT10MH01-225A2020-W - WUJIN SPIKE Trimmer Carbon Potentiometer:

  • Compact size (10mm) for dense PCB layouts
  • Vertical mounting for efficient use of board space
  • Single-turn design for intuitive and quick adjustments
  • 2.2MΩ resistance value suitable for a wide range of applications
  • Cost-effective adjustability with ±20% tolerance.

Versatile Applications of PT10MH01-225A2020-W - WUJIN SPIKE Trimmer Carbon Potentiometer:

  • Industrial control systems
  • Audio/video equipment
  • Medical devices
  • Test and measurement instruments
  • Power supplies
  • Many other applications that require precise resistance control.
