PIHER PT10MH01-504A2020-S, TRIMPOT CARBON H 10MM 500K ±20% ALLEN

PT10MH01-504A2020-S
brand logo

HT Part No. HT193342

Mfr. Part No. PT10MH01-504A2020-S

Manufacturer: PIHER

Technical Documents: Datasheet(datasheets)

1400 - In Stock pcs
Price:
£ 0.22
Units Per Unit Price
1 - 999 £ 0.22
1000 + £ 0.19
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Rohs ROHS
Keyword karbon trimpot, japon tip trimpot, kombi trimpot, kombi kart trimpot
Adjust Method Horizontal
Packaging BULK&BOX
Mounting Type THT
Temperature Coefficient ±300 ppm/°C
Shaft Without Shaft
Manufacturer PIHER
Series PT10
Size 10mm
Number of Turn Single Turn
Resistance Value 500K Ohms
Taper Linear
Rotors Allen
Mounting method Vertical
Tolerance ±20%

More Information

The PIHER PT10MH01-504A2020-S is a precision trimmer potentiometer, commonly known as a trimpot, designed for fine-tuning and adjusting resistance in electronic circuits. This model features a 10mm carbon element with a resistance value of 500K ohms and a tolerance of ±20%. It utilises an Allen key for adjustment, offering precise control over the resistance setting. Trimpots like the PT10MH01-504A2020-S are crucial in applications requiring adjustable calibration and tuning to ensure optimal circuit performance.

Salient Features and Benefits of Using the PIHER PT10MH01-504A2020-S, Trimmer Potentiometer

  • Carbon element
  • Allen key adjustment
  • Single turn
  • Precise resistance tuning
  • Compact size suitable for tight spaces
  • Easy to adjust with an Allen key
  • High reliability and stability
  • Cost-effective solution for circuit calibration

Where to Use the PIHER PT10MH01-504A2020-S, Trimmer Potentiometer?

  • Calibration of Sensors and Instruments
  • Fine-Tuning Audio and RF Circuits
  • Adjusting Bias and Offset in Amplifiers
  • Setting Reference Voltages in Power Supplies
  • Tuning Filter Frequencies in Communication Devices
