PIHER PT15LV02-502A2020-S, TRIMPOT CARBON V 15MM 5K ±20% SCREWDRIVER

PT15LV02-502A2020-S
brand logo

HT Part No. HT193340

Mfr. Part No. PT15LV02-502A2020-S

Manufacturer: PIHER

Technical Documents:

1 - In Stock pcs
Price:
£ 0.26
Units Per Unit Prices
1 - 399 £ 0.26
400 + £ 0.23
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Rohs ROHS
Resistance Value 5K Ohms
Manufacturer PIHER
Packaging BULK&BOX
Series PT15
Mounting Type THT
Taper Linear
Mounting method Horizontal
Temperature Coefficient ±300 ppm/°C
Keyword karbon trimpot, japon tip trimpot, kombi trimpot, kombi kart trimpot
Size 15mm
Rotors Screwdriver
Adjust Method Vertical
Tolerance ±20%
Number of Turn Single Turn
Shaft Without Shaft

More Information

The PIHER PT15LV02-502A2020-S is a precision trim pot (trimming potentiometer) designed for fine-tuning and calibrating electronic circuits. It features a 15mm carbon composition rotary element with a 5K ohm resistance value and a ±20% tolerance. The trim pot is operated using a screwdriver, allowing for precise adjustments. Its compact size and robust design make it suitable for various applications where stable and reliable performance is crucial.

Salient Features and Benefits of Using the PIHER PT15LV02-502A2020-S, Trimmer Potentiometer

  • Adjustment: Screwdriver-operated
  • Element: Carbon composition
  • Mounting: Surface mount (SCREWDRIVER)
  • High Precision: Allows accurate adjustments in circuits.
  • Compact Size: Fits in tight spaces within electronic assemblies.
  • Durability: Carbon composition ensures long-lasting performance.
  • Ease of Use: Screwdriver adjustment simplifies calibration.

Application Versatility of the PIHER PT15LV02-502A2020-S, Trimmer Potentiometer

  • Electronic Circuit Calibration: Ideal for fine-tuning analog circuits.
  • Audio Equipment: Used for adjusting audio levels in equipment.
  • Test Equipment: Helps calibrate and adjust measurement instruments.
  • Consumer Electronics: Applied in various consumer electronic components for precise control settings.
